MSW - MSWSGV
Industries & Applications:OurStainless-steel all-in-one exhaustsystem is suitable forinstallation as a chimneystack orlinerservicing:
- Made of all cold-rolled ASTM carbon steel. Extremely rigid, with a Limited 10-Year Warranty.
- Factory-built duct eliminates welding in the field and assures quality and reliability. Factory-applied gaskets for Liquid-tight joints.
- Available in Round and Rectangular configurations in sizes 6” to 48” .
- Smooth flow and known resistance for accurate factory pressure calculations.
- Custom Parts and fittings available with our in-house engineering team.
Boilers & Water Heaters
Engine and CHP exhaust
Grease Duct
Chemical & Pharmaceutical
Waste & Recycling
Food Processing
Dryer vents,
Oven and process stacks
paint booth exhaust
Industries & Applications: Our Stainless-steel all-in-one exhaust system is suitable for installation as a chimney stack or liner servicing:
- Boilers & Water Heaters: Used for venting boilers and water heaters in commercial/multi-unit and industrial buildings for condensing and noncondensing appliances.
- Engine and CHP exhaust.
- Grease Duct: Used for commercial kitchen ventilation systems.
- dryer vents,
- fume venting,
- coffee roasters
- oven and process stacks, and
- paint booth exhaust.
- Chemical & Pharmaceutical: Selected for its superior corrosion resistance against acidic fumes and for maintaining sterile environments in labs or production plants.
- Waste & Recycling: Used for pneumatic conveying of scrap metal, waste paper, glass reclaimers, and tire recycling.
- Food Processing: Preferred for its hygienic, non-porous surface that resists mold and bacteria while handling high-moisture or acidic environments.
Fuel:
Applicable for all fuels: gas, oil, and solid fuels, including wood.
Features:
- Made of all cold-rolled ASTM carbon steel. Extremely rigid, with a Limited 10-Year Warranty.
- Factory-built duct eliminates welding in the field and assures quality and reliability. Factory-applied gaskets for Liquid-tight joints.
- Available in Round and Rectangular configurations in sizes 6” to 48” .
- Smooth flow and known resistance for accurate factory pressure calculations.
- Custom Parts and fittings available with our in-house engineering team.
Material:
Made of minimum 0.0035″ cold rolled ASTM carbon steel 1” wide flange is minimum 12-gauge (0.109”) carbon steel.
Sizes:
Duct is available in either round, square or rectangular configurations. Round duct is available from 6” to 48”. Square duct is available in sizes from 6” x 6” to 36” x 36”. Rectangular duct is available in sizes from 6” x 8” to 27” x 48”. The maximum allowable width-to-height ratio is 6 to 1, for instance, 36” x 6”.
Wall thickness:
Minimum 0.035”
Connection:
Connection is flange-to-flange bolted
Supplied sealant is used on the flange to make a seal
